Complex disordered systems: Problems

Colloids

Interaction of two charged colloidal spheres

Adapted from J Dhont, K, Kang (1996) An Introduction to Dynamics of Colloids. Elsevier.

Consider a colloidal particle of total charge \(Q\) located at the origin, immersed in a solvent of permittivity \(\varepsilon = \varepsilon_0 \varepsilon_r\). The solvent contains a symmetric electrolyte with two mobile ionic species:

Cations of charge \(+ze\) and bulk concentration \(n_0\),
Anions of charge \(-ze\) and bulk concentration \(n_0\).

Show that The mean electrostatic potential \(\phi(\mathbf{r})\) satisfies Poisson’s equation: \[ \nabla^2 \phi(\mathbf{r}) = -\frac{1}{\varepsilon} \left[ z e\, n_+(\mathbf{r}) - z e\, n_-(\mathbf{r}) + Q \delta(\mathbf{r}) \right]. \]

Assuming the ions form an ideal gas in thermal equilibrium, their local densities follow Boltzmann distributions: \[ n_+(\mathbf{r}) = n_0 \exp[-\beta z e\, \phi(\mathbf{r})], \qquad n_-(\mathbf{r}) = n_0 \exp[+\beta z e\, \phi(\mathbf{r})], \] where \(\beta = 1/(k_B T)\).
Use these expressions to obtain the (simplified) nonlinear Poisson–Boltzmann equation : \[ \nabla^2 \phi(\mathbf{r}) = \frac{2 z e n_0}{\varepsilon} \sinh\big(\beta z e\, \phi(\mathbf{r})\big) - \frac{Q}{\varepsilon}\delta(\mathbf{r}). \]
Find physical conditions to linearise the equation.
Solve the resulting linear equation for spherical symmetry to obtain the screened Coulomb (Debye–Hückel) potential: \[ \phi(r) = \frac{Q}{4\pi \varepsilon} \frac{e^{-\kappa r}}{r}, \qquad \kappa^2 = \frac{2 n_0 z^2 e^2}{\varepsilon k_B T}. \]

The parameter \(\kappa^{-1}\) is the Debye screening length, and the solution shows that ionic screening converts the long-range Coulomb potential into a short-range Yukawa potential.

The following real to Fourier spcace mappings may be useful

Real space	Fourier space
\(f(\mathbf{r})\)	\(f(\mathbf{k})\)
\(\nabla^2 f(\mathbf{r})\)	\(-k^2 f(\mathbf{k})\)
\(\delta(\mathbf{r})\)	\(1\)
\(\dfrac{e^{-\kappa r}}{4\pi r}\)	\(\dfrac{1}{k^2 + \kappa^2}\)

Solution

We start by considering a single colloidal particle of total charge \(Q\) located at the origin, immersed in a solvent characterized by a permittivity \(\varepsilon = \varepsilon_0 \varepsilon_r\). The solvent contains a symmetric electrolyte composed of two mobile ionic species: cations of charge \(+ze\) and bulk concentration \(n_0\), and anions of charge \(-ze\) with the same bulk concentration \(n_0\). The overall system is globally electroneutral in the bulk, so the net ionic charge far from the colloid is zero. The presence of the charged colloid generates an electrostatic potential \(\phi(\mathbf{r})\) in the surrounding medium.

The mean electrostatic potential satisfies Poisson’s equation, which relates the divergence of the electric field to the local charge density. In this system, the total charge density consists of the fixed colloidal charge, represented by \(Q \delta(\mathbf{r})\), and the contribution from the mobile ions, which depends on their local concentrations. This gives \[ \nabla^2 \phi(\mathbf{r}) = -\frac{1}{\varepsilon} \left[ z e\, n_+(\mathbf{r}) - z e\, n_-(\mathbf{r}) + Q \delta(\mathbf{r}) \right]. \]

To relate the ionic densities to the electrostatic potential, we assume the ions behave as an ideal gas in thermal equilibrium. Each ion experiences a potential energy proportional to its charge times the local potential, \(U_\pm(\mathbf{r}) = \pm z e \phi(\mathbf{r})\). In equilibrium, the number density of each species follows the Boltzmann distribution, so the cation and anion densities are \[ n_+(\mathbf{r}) = n_0 \exp[-\beta z e\, \phi(\mathbf{r})], \qquad n_-(\mathbf{r}) = n_0 \exp[+\beta z e\, \phi(\mathbf{r})], \] where \(\beta = 1/(k_B T)\) is the inverse thermal energy. This captures the intuitive fact that cations are repelled by positive potentials and attracted to negative potentials, while anions behave oppositely.

Substituting these expressions for \(n_+\) and \(n_-\) into Poisson’s equation yields \[ \nabla^2 \phi(\mathbf{r}) = -\frac{1}{\varepsilon} \Big[ z e n_0 e^{-\beta z e \phi} - z e n_0 e^{\beta z e \phi} + Q \delta(\mathbf{r}) \Big]. \] The difference of exponentials can be written as twice a hyperbolic sine, leading to the nonlinear Poisson–Boltzmann equation \[ \nabla^2 \phi(\mathbf{r}) = \frac{2 z e n_0}{\varepsilon} \sinh\big(\beta z e\, \phi(\mathbf{r})\big) - \frac{Q}{\varepsilon}\delta(\mathbf{r}). \] This equation describes how the potential generated by the colloid is screened by the surrounding ions. The nonlinearity arises because the ionic response depends exponentially on the potential itself.

The equation can be linearized under the condition that the potential is small compared to the thermal voltage, specifically when \(|\beta z e \phi(\mathbf{r})| \ll 1\). In this limit, the hyperbolic sine can be approximated by its argument

\[\sinh(\beta z e \phi) \approx \beta z e \phi.\]

The Poisson–Boltzmann equation then reduces to a linear differential equation

\[ \nabla^2 \phi(\mathbf{r}) - \kappa^2 \phi(\mathbf{r}) = -\frac{Q}{\varepsilon} \delta(\mathbf{r}), \]

where the inverse Debye length \(\kappa\) is defined by

\[ \kappa^2 = \frac{2 n_0 z^2 e^2}{\varepsilon k_B T}. \]

This linearized equation is known as the Debye–Hückel equation and describes the potential around a point charge in a screening medium.

This can be solved in Fourier space using the relations:

Real space	Fourier space
\(f(\mathbf{r})\)	\(f(\mathbf{k})\)
\(\nabla^2 f(\mathbf{r})\)	\(-k^2 f(\mathbf{k})\)
\(\delta(\mathbf{r})\)	\(1\)
\(\dfrac{e^{-\kappa r}}{4\pi r}\)	\(\dfrac{1}{k^2 + \kappa^2}\)

This gives

\[ \phi(r) = \frac{Q}{4\pi \varepsilon} \frac{e^{-\kappa r}}{r}. \] At short distances (\(r \ll \kappa^{-1}\)), the potential reduces to the familiar Coulomb form, while at larger distances it decays exponentially due to ionic screening. The characteristic decay length \(\kappa^{-1}\) is the Debye screening length, which increases with decreasing ionic strength and temperature. This solution illustrates how the electrolyte effectively screens the electrostatic interactions between colloidal particles, converting the long-range Coulomb potential into a short-range interaction that governs the stability and dynamics of colloidal suspensions.

Note. In the linearised regime, the Poisson-Boltzmann equation reads

\[ \nabla^2 \phi-\kappa^2 \phi=-\frac{Q}{\varepsilon} \delta(\mathbf{r}) \]

A similar equation exists in field theory for a massive scalar field \(\Phi(\mathbf{r})\): it is the Klein-Gordon equation in Euclidean space

\[ \left(-\nabla^2+m^2\right) \Phi(\mathbf{r})=J(\mathbf{r}) \]

It is easy to identify the field the mass and the source with the respective static potential field, the Debye screening parameter and the point charge. The Yukawa potential is then simply the propagator (the Green’s function).

Second virial coefficient for depletion interactions

Consider a dilute suspension of spherical colloidal particles of radius \(R_c\) in a solution of small ideal polymer coils of radius \(R_p \ll R_c\). The polymers are non-adsorbing and behave as an ideal gas outside the colloids. The colloids interact via the Asakura–Oosawa depletion potential \(U_{\rm AO}(r)\):

\[ U_{\rm AO}(r) = \begin{cases} \infty, & r < 2 R_c \\[2mm] -\Pi\, V_{\rm overlap}(r), & 2 R_c \le r \le 2 R_c + 2 R_p \\[1mm] 0, & r > 2 R_c + 2 R_p \end{cases} \]

where \(r\) is the center-to-center distance, \(\Pi = n_p k_B T\) is the so called osmotic pressure of the polymer solution, and \(V_{\rm overlap}(r)\) is the overlap volume of the depletion zones, given by

\[ V_{\text {overlap }}(r)=\frac{\pi\left(4 R_{\mathrm{eff}}+r\right)\left(2 R_{\mathrm{eff}}-r\right)^2}{12}, \]

with \(R_{eff} = R_c+R_p\).

Write the expression for the second virial coefficient \(B_2\) in terms of the interaction potential:

\[ B_2 = -2 \pi \int_0^\infty \left( e^{-\beta U_{\rm AO}(r)} - 1 \right) r^2 dr \]
Assuming the polymer-induced attraction is weak (\(\beta |U_{\rm AO}(r)| \ll 1\)) and that the polymers are much smaller than the colloids, expand the exponential to first order and simplify the integral.
Express the resulting \(B_2\) in terms of \(R_c\), \(R_p\), and the polymer osmotic pressure \(\Pi\).
Discuss qualitatively how \(B_2\) depends on polymer concentration and size, and explain what a negative \(B_2\) implies for colloidal aggregation.

Solution

The second virial coefficient \(B_2\) measures the effective two-body contribution to the pressure of a dilute colloidal suspension, following the virial expansion. It is defined for a pairwise potential \(U(r)\) as:

\[ B_2 = -2\pi \int_0^\infty \left( e^{-\beta U(r)} - 1 \right) r^2 dr. \]

Here, \(U(r) = U_{\mathrm{ AO}}(r)\) is the Asakura–Oosawa depletion potential.

Rewrite \(B_2\)

The AO potential has three regions:
- Hard-core region (\(r < 2 R_c\)), where \(U = \infty \rightarrow e^{-\beta U} = 0\). The integrand becomes \(-1\), giving contribution:
\[ B_2^{\mathrm HC} = -2\pi \int_0^{2R_c} (-1) r^2 dr = 2\pi \int_0^{2R_c} r^2 dr = \frac{16\pi}{3} R_c^3, \]

which is just the hard-sphere contribution.
- Depletion region (\(2R_c \le r \le 2R_c + 2 R_p\)), where \(U(r) = -\Pi V_{\mathrm overlap}(r)\).
- No interaction (\(r > 2R_c + 2 R_p\)), where \(U = 0 \rightarrow e^{-\beta U} - 1 = 0\).

The overlap is written as (lecture notes) \[ V_{\text {overlap }}(r)=\frac{4 \pi}{3} R_d^3\left[1-\frac{3}{4} \frac{r}{R_d}+\frac{1}{16}\left(\frac{r}{R_d}\right)^3\right], \quad r \leq R_d=2R_c+2R_p \]

and can be shown to be equivalent to

\[ V_{\text {overlap }}(r)=\frac{\pi\left(4 R_{\mathrm{eff}}+r\right)\left(2 R_{\mathrm{eff}}-r\right)^2}{12} \]

So the integral reduces to contributions from \(r < 2R_c\) (hard core) and \(2R_c \le r \le 2R_c + 2R_p\) (depletion).

Linearize the exponential. For weak polymer-induced attraction, \(\beta |U| = \beta \Pi V_{\mathrm overlap} \ll 1\), we can expand:

\[ e^{-\beta U(r)} \approx 1 - \beta U(r) = 1 + \beta \Pi V_{\mathrm overlap}(r). \]

Then the integrand in the depletion region becomes:

\[ -(e^{-\beta U} - 1) \approx -\beta \Pi V_{\mathrm overlap}(r). \]

So the contribution to \(B_2\) from the depletion region is:

\[ B_2^{\mathrm dep} = -2\pi \int_{2R_c}^{2R_c + 2R_p} \big( e^{-\beta U} - 1 \big) r^2 dr \approx -2\pi \beta \Pi \int_{2R_c}^{2R_c + 2R_p} V_{\mathrm overlap}(r) r^2 dr. \]

Express \(B_2\) in terms of \(R_c\), \(R_p\), \(\Pi\)

Combining the hard-core and depletion contributions, the second virial coefficient is

\[ B_2 = \frac{16\pi}{3} R_c^3 - 2\pi \beta \Pi \int_{2R_c}^{2R_c + 2R_p} V_{\mathrm{overlap}}(r)\, r^2 dr \]

We then calculate the second integral we just need to choose how to represent the overlap. We use the second expression above and leverage the fact that \(R_p \ll R_c\) and that then the integral runs over \(r=2R_C+x\) with \(x\in[0,2R_p]\), so with \(x\) clearly subleading

So, then

\[ 4R_{\mathrm eff}+r = 6 R_c+4 R_p+x \]

and

\[ 2R_{\mathrm eff}-r = 2R_c+2R_p-2R_c-x= 2R_p-x \]

So together

\[ V_{\mathrm overlap}(x) = \dfrac{\pi(6R_c+4R_p+x)(2R_p-x)^2}{12} \]

dropping subleading contributions leads to \[ V_{\mathrm overlap}(x) \approx \dfrac{6\pi R_c(2R_p-x)^2}{12} \]

Then, we rewrite

\[\int_{2R_c}^{2R_c + 2R_p} V_{\mathrm{overlap}}(r)\, r^2 dr\]

as \[\int_{0}^{2R_p} V_{\mathrm{overlap}}(x)\, (2R_c+x)^2 dx\]

and approximate as \[ \approx (2 R_c)^2 \int_{0}^{2R_p } V_{\mathrm{overlap}}(x)dx\]

and then

\[ B_2\approx \frac{16\pi}{3} R_c^3 -2 \pi \beta \Pi\left(2 R_c\right)^2 \int_0^{2 R_p} \frac{\pi}{2} R_c\left(2 R_p-x\right)^2 d x \]

So we finally integrate

\[ \int_0^{2 R_p}\left(2 R_p-x\right)^2 d x \]

via a change of variable \(y=2 R_p-x\)

\[ \int_0^{2 R_p}\left(2 R_p-x\right)^2 d x=\int_{2 R_p}^0 y^2(-d y)=\int_0^{2 R_p} y^2 d y=\frac{\left(2 R_p\right)^3}{3}=\frac{8 R_p^3}{3} \]

which leads to

\[ B_2 \approx\frac{16\pi}{3} R_c^3 -\frac{32 \pi^2}{3} \beta \Pi R_c^3 R_p^3 \]

where \(R_c\) is the colloid radius, \(R_p\) is the polymer radius, \(\Pi\) is the osmotic pressure of the polymer solution, and \(V_{\mathrm{overlap}}(r)\) is the overlap volume between two colloids at separation \(r\). This formula shows how \(B_2\) depends explicitly on \(R_c\), \(R_p\), and \(\Pi\).

Physical interpretation

\(B_2\) decreases with increasing polymer concentration (via \(\Pi\)) and polymer size (\(R_p\)).
When the depletion attraction is strong enough, \(B_2\) can become negative, which signals that attractive interactions dominate over repulsion.
Negative \(B_2\) implies a tendency for colloidal aggregation or even phase separation, because the effective interaction favuors close approach of colloids.

Colloids and sedimentation

A particle suspended in a liquid can be defined as colloidal if the kinetic energy of its thermally-driven Brownian motion is large enough to prevent it from settling completely to the bottom of the container under the influence of gravity.

A second definition of a colloid is a particle whose gravitational Peclet number Pe is significantly smaller than 1. (The gravitational Peclet number is the ratio of the time taken by a particle to diffuse a distance equal to its radius to the time taken by it to sediment the same distance under gravity.)

Show that these two definitions of a colloid are essentially equivalent.

Solution

To show the equivalence between these two definitions, we need to establish the relationship between thermal energy dominating over gravitational settling and the gravitational Peclet number being much less than 1.

For the first definiton, a spherical particle of radius \(a\) and density \(\rho_p\) in a fluid of density \(\rho_f\), the gravitational force is: \[F_g = \frac{4\pi a^3}{3}(\rho_p - \rho_f)g\]

The gravitational potential energy difference over a distance equal to the particle radius is: \[U_g = F_g \cdot a = \frac{4\pi a^4}{3}(\rho_p - \rho_f)g\]

For thermal motion to dominate, we require: \[k_B T \gg U_g = \frac{4\pi a^4}{3}(\rho_p - \rho_f)g\]

For th second definition, the gravitational Peclet number is defined as: \[\text{Pe} = \frac{t_{\text{diffusion}}}{t_{\text{sedimentation}}}\]

For diffusion over distance \(a\): \[t_{\text{diffusion}} = \frac{a^2}{D}\] where \(D\) is the diffusion coefficient given by the Einstein relation: \(D = \frac{k_B T}{6\pi\eta a}\).

For sedimentation over distance \(a\) under Stokes drag: \[t_{\text{sedimentation}} = \frac{a}{v_s}\] where the sedimentation velocity is: \(v_s = \frac{F_g}{6\pi\eta a} = \frac{2a^2(\rho_p - \rho_f)g}{9\eta}\).

Therefore: \[\text{Pe} = \frac{a^2/D}{a/v_s} = \frac{a v_s}{D} = \frac{a \cdot \frac{2a^2(\rho_p - \rho_f)g}{9\eta}}{\frac{k_B T}{6\pi\eta a}}\]

Simplifying: \[\text{Pe} = \frac{2a^3(\rho_p - \rho_f)g \cdot 6\pi\eta a}{9\eta \cdot k_B T} = \frac{4\pi a^4(\rho_p - \rho_f)g}{3k_B T}\]

From the first definition, colloidal behavior requires: \[k_B T \gg \frac{4\pi a^4}{3}(\rho_p - \rho_f)g\]

This is equivalent to: \[\frac{4\pi a^4(\rho_p - \rho_f)g}{3k_B T} \ll 1\]

But this is exactly the condition \(\text{Pe} \ll 1\) from the second definition.

Therefore, the two definitions are mathematically equivalent: thermal energy dominance over gravitational settling occurs precisely when the gravitational Peclet number is much smaller than unity. Both conditions ensure that Brownian motion prevents complete sedimentation, which is the hallmark of colloidal behavior.

Hard Rods and Cavity Function

Consider a 1-dimensional (1D) system of Hard Rods of length \(\sigma\). The number density is \(\rho\), and the equation of state is exactly known as (Tonks equation): \(Z_{\rm comp} = \frac{1}{1 - \rho \sigma}\).

The potential is: \[ u(x) = \begin{cases} \infty, & x < \sigma \\ 0, & x \ge \sigma \end{cases} \]

The pair distribution function at contact, \(g(\sigma^+)\), is known to be directly related to the equation of state by the 1D virial theorem (see lecture notes): \[ Z = 1 + \rho \sigma g(\sigma^+) \]

Calculate \(g(\sigma^+)\) for the 1D hard rod system using the Tonks equation of state and the 1D virial theorem.
Determine the value of the Boltzmann factor, \(e^{-\beta u(\sigma)}\), at contact.
Determine the value of the cavity Function, \(y(\sigma)= e^{\beta U(r)}g(r)\), at contact.
Explain the physical meaning of \(y(\sigma)\). How does it differ from \(g(\sigma^+)\) in its interpretation?
Derive the full \(g(r)\) by maximising the (Shannon) entropy\[ S[p]=-\int_0^{\infty} p(l) \ln p(l) d l \] for the probability to find a gap of length \(l\). Assume that the gaps are independent for simplicity and see that the \(g(r)\) you obtain matches the previous assumptions.

Solution

Calculate \(g(\sigma^+)\)

We use the Tonks equation and the virial theorem: \[ Z_{\mathrm comp} = \frac{1}{1 - \rho \sigma} \]

\[ Z_{\mathrm comp} = 1 + \rho \sigma g(\sigma^+) \] Setting the two expressions for \(Z\) equal: \[ 1 + \rho \sigma g(\sigma^+) = \frac{1}{1 - \rho \sigma} \] Isolating \(g(\sigma^+)\): \[ \rho \sigma g(\sigma^+) = \frac{1}{1 - \rho \sigma} - 1 \] Combine the right side using a common denominator: \[ \rho \sigma g(\sigma^+) = \frac{1 - (1 - \rho \sigma)}{1 - \rho \sigma} = \frac{\rho \sigma}{1 - \rho \sigma} \] Dividing by \(\rho \sigma\): \[ g(\sigma^+) = \frac{1}{1 - \rho \sigma} \] This is the exact, analytic expression for the contact value for 1D hard rods.

Determine \(e^{-\beta u(\sigma)}\)

The Boltzmann factor \(e^{-\beta u(x)}\) at contact \(x = \sigma\) is determined by the potential \(u(x)\): \[ e^{-\beta u(\sigma)} = e^{-\beta (0)} = 1 \]

Since the potential is zero for \(x \ge \sigma\), the particles are not interacting via the direct core repulsion precisely at \(\sigma^+\).

Determine \(y(\sigma)\)

The cavity function \(y(x)\) is related to \(g(x)\) and the Boltzmann factor: \[ g(x) = e^{-\beta u(x)} y(x) \] At contact, \(x = \sigma\): \[ g(\sigma^+) = e^{-\beta u(\sigma)} y(\sigma) \] Substituting the results from (1) and (2): \[ \frac{1}{1 - \rho \sigma} = (1) \cdot y(\sigma) \] Therefore, the cavity function at contact is: \[ y(\sigma) = \frac{1}{1 - \rho \sigma} \] In this 1D case, \(g(\sigma^+)\) and \(y(\sigma)\) are equal.

Explain the meaning of \(y(\sigma)\)

Let’s think of the direct correlation function

It is useful to think about the Pecus Yevick apprximation for the direct correlation function

\[c(r) = (1-e^{+\beta u(r)}) (h(r)+1)\]

(see lecture notes).

This can be rewritten as

\[c(r) = (1-e^{+\beta u(r)}) g(r) = (1-e^{+\beta u(r)}) y(r)e^{-\beta u(r)}\]

and then

\[c(r) = (e-{\beta u(r)}-1) y(r)= f(r) y(r)\]

where we used the Mayer f-function. Both \(f(r)\) and \(y(r)\) are continuous and differentiable, making solving the Ornstein Zernicke problem a tractable problem. In particular, \(y(r)\) allows us to remove the discontinuities cause by the potential at short distances and focus on the correlations produced outside of the core.

The \(g(r)\) is the total probability of finding a particle exactly one rod length (\(\sigma\)) away from another particle, given the direct physical repulsion (\(\sigma^-\) region) and the indirect correlations (the rest of the fluid). It is an experimental, measurable quantity directly linked to pressure via the virial theorem.

The cavity function \(y(r)\) is the probability of finding a particle at distance \(\sigma\) if the direct, instantaneous repulsive interaction \(u(x)\) were suddenly removed (i.e., if \(u(\sigma)\) was momentarily zero). It represents the correlation due only to the structure induced by the surrounding fluid.

We can reread the PY appoximation in this light

\[c(r) = g_{\mathrm total}- g_{\mathrm indirect}\]

We assume that there is a potential of mean force \(w(r)\) generating the correlations, such that

\[g(r) = g_{\mathrm total} (r)= e^{-beta w(r)}\]

and then we decide to approximate the indirect but by removing the interparticle potential from the potential of mean force

\[ g_{\mathrm indirect} = e^{-\beta (w(r)=u(r))}\]

Then the PY approximation with the \(c(r) =f(r) y(r)\) comes about.

Derivation

Hard rods cannot overlap, so: \[ g(r)=0\quad(r<\sigma). \]

Let the free gap between rods be

\[l = r-\sigma \ge 0\].

We use the maximum entropy principle to find \(p(l)\).

We want to maximise

\[ S[p]=-\int_0^{\infty} p(l) \ln p(l) d l \]

subject to

\[ \int_0^{\infty} p(l) d l=1, \quad \int_0^{\infty} l p(l) d l=\lambda \]

where the mean free gap is

\[\lambda=\frac{1-\rho\sigma}{\rho}\]

Via Lagrange multipliers

\[ \delta\left[-\int p \ln p d l+\alpha\left(\int p d l-1\right)+\gamma\left(\int l p d l-\lambda\right)\right]=0 \]

and then

\[ p(l)=\frac{1}{\lambda} e^{-l/\lambda} \]

and \[ \gamma=-\frac{1}{\lambda}, \quad \alpha=1-\ln \lambda \]

We then convert from gap probability to pair correlation.

The pair correlation is the probability to find the particle as some position \(r\) scaled by the density: \[ g(r)=\frac{p(r-\sigma)}{\rho}. \]

Substitute \(p(l)\) and \(\lambda\):

\[ g(r)=\frac{1}{(1-\rho\sigma)}\exp\left[-\frac{\rho(r-\sigma)}{1-\rho\sigma}\right]. \]

Checks: \[ g(\sigma^+) = \frac{1}{1-\rho\sigma}. \]

Matches the 1D hard-rod equation of state: \[ P = \frac{\rho k_BT}{1-\rho\sigma}. \]

Polymers

Polymer in theta solvent

Consider a polymeric molecule initially a solvent at temperature \(T_1=\Theta\) (i.e. at the so-called theta temperature of the solvent). It is composed of \(N=10^5\) identical monomers of size \(b=0.2 \text{nm}\).

Estimate its root-mean-square end-to-end distance.
Provide a second estimate at a second temperature \(T_2\gg \Theta\)

Solution

The problem simply requires us to remember the following:

The temperature \(\Theta\) is the one at which the freeley-jointed chain model is most suitable. In such case \(R_{rms} = \sqrt{\langle R^2\rangle} = b N^{1/2}\approx 63 \text{nm}\)
For temepratures much higher than \(\Theta\) the chain is swollen and excluded volumes effects dominate, so that \(R_{rms} = \sqrt{\langle R^2\rangle} = b N^{3/5}=200 \text{nm}\)

Flory exponent for a polymer globule

Consider a single flexible polymer of \(N\) monomers, each of size \(b\), in a poor solvent (i.e., \(T < \Theta\)), so that the polymer collapses into a dense globule.

The entropic contribution for the chain can be approximated (see notes) with

\[ S = \frac{-3 k_B R^2}{2 N b^2} \]

where \(R\) is the radius of the globule (essentially proportional to the root means quared distance of the end to ened vector).

Try to figure out why this leads to what is called as the “elastic” free energy of the chain.

The globule is dense. Write the interaction free energy using the virial expansion, noting that \(\rho=N/R^3\) stopping at order three.

We state that the second virial drives the collapse (attraction) while the third virial is repulsive and prevents complete collapse.

Minimise the total free energy to obtain a function \(f(R)=0\). Show that if we assume that \(R\) grows with N more slowly than in the theta conditions, the entropic part of the resulting function of R can beneglected.
Proceed with the approximation and extract the Flory exponent \(\nu\) for the globule, defined by \(R \sim N^\nu\): how is it different for other solvent conditions?

Solution

For the entropy \[ S = \frac{-3 k_B R^2}{2 N b^2} \]

then the entropic free energy contribution is \[F_{\text{ent}} = -T S = \frac{3 k_B T R^2}{2 N b^2}\]

which is quadratic in \(R\) likre an elastic energy.

We can write

\[ \frac{F_{\text {int }}}{k_B T} \sim B_2 \rho^2+B_3 \rho^3 \]

\[ F_{\mathrm{int}}(R) \sim k_B T\left(\frac{v N^2}{R^3}+\frac{w N^3}{R^6}\right) . \]

where we renamed the second virial coefficient \(B_2 = v\) and the third virial coefficient \(B_3 = w\).

Sum the two entropic and interacting contributions: \[ F(R) \sim k_B T\left[\frac{3 R^2}{2 N b^2}+\frac{v N^2}{R^3}+\frac{w N^3}{R^6}\right] \]

At equilibrium, the free energy is minimised with respect to \(R\).

Set \(\frac{dF}{dR} = 0\): \[ \dfrac{dF}{dR}= k_BT \left(\dfrac{3R}{Nb^2}-3vN^2 R^{-4}-6 w N^3 R^{-7}\right)=0 \]

Multiply by \(NR^7\)

\[ \dfrac{3R^8}{b^2}-3vN^3 R^{3}-6 w N^4 =0 \]

If \(R\sim N^\nu\) with \(\nu < 1/2\) (i.e., the chain is more collapsed than in theta conditions) then the first term scales as \(N^{8\nu}\), the second as \(N^{3+3\nu}\) and the third as \(N^{4}\).

For \(\nu=1/2\) the first term scales as \(N^{4}\), the second as \(N^{4.5}\) and the third as \(N^{4}\).

For smaller \(\nu\) the first term becomes subleading with respect to the other two.

So we approximate the minimisation condition as

\[-3vN^3 R^{3}-6 w N^4 = 0\]

and get \[ R \propto N^{1/3} \]

Thus, for a collapsed globule: \[ R \sim N^{1/3} \]

So the Flory exponent is \(\nu = 1/3\) for a globule (dense sphere).

For a theta solvent (ideal chain): \(\nu = 1/2\)
For a good solvent (swollen coil): \(\nu \approx 3/5\)

In a poor solvent, the polymer collapses into a dense globule with \(R \sim N^{1/3}\) (something you could have guessed even without the calculation…).

Liquid crystals

Linearising Maier-Saupe

In the Maier-Saupe mean-field theory of nematic liquid crystals, the orientation distribution function of rod-like molecules is given by

\[ p(\theta)=\frac{1}{Z}\exp\big(\lambda P_2(\cos\theta)\big),\qquad Z=\int_0^\pi \exp\big(\lambda P_2(\cos\theta)\big)\sin\theta\,d\theta, \] where \(\lambda=uS/(k_BT)\) and \[ S=\langle P_2(\cos\theta)\rangle =\frac{\int_0^\pi P_2(\cos\theta)p(\theta)\sin\theta\,d\theta}{\int_0^\pi p(\theta)\sin\theta\,d\theta}. \]

This leads to the implicit (“self-consistent”) relation \[ S=\frac{\int_0^\pi P_2(\cos\theta)e^{\lambda P_2(\cos\theta)}\sin\theta\,d\theta}{\int_0^\pi e^{\lambda P_2(\cos\theta)}\sin\theta\,d\theta}. \]

You may use \[ \int_0^\pi P_2(\cos\theta)\sin\theta\,d\theta=0,\qquad \int_0^\pi [P_2(\cos\theta)]^2\sin\theta\,d\theta=\frac{2}{5} . \]

Explain why the above equation is implicit and why it means to linearise it near the isotropic phase.
Assuming \(\lambda\) is small, expand \[ e^{\lambda P_2(\cos\theta)} \] to first order in \(\lambda\).
Using your expansion derive the linearised relation between \(S\) and \(\lambda\).
Using \(\lambda=uS/(k_BT)\), determine the value of \(k_BT/u\) at which a non-zero solution for \(S\) first appears.

Solution

Why the equation is implicit and what linearization means

The equation is implicit because \(S\) appears on both sides: explicitly on the left side, and implicitly on the right side through \(\lambda = uS/(k_BT)\). To solve for \(S\), we need to find values that satisfy this self-consistency condition.

Linearization near the isotropic phase means we expand around \(S = 0\) (the isotropic state where there’s no preferred orientation) and keep only first-order terms in small parameters. This allows us to find the critical temperature where nematic order first appears.

Expand the exponential to first order

For small \(\lambda\), we expand: \[ e^{\lambda P_2(\cos\theta)} \approx 1 + \lambda P_2(\cos\theta) \]

Derive the linearized relation

Substituting the expansion into the self-consistent equation:

Numerator: \[ \int_0^\pi P_2(\cos\theta)[1 + \lambda P_2(\cos\theta)]\sin\theta\,d\theta = \int_0^\pi P_2(\cos\theta)\sin\theta\,d\theta + \lambda\int_0^\pi [P_2(\cos\theta)]^2\sin\theta\,d\theta \]

Using the given integrals: \[ = 0 + \lambda \cdot \frac{2}{5} = \frac{2\lambda}{5} \]

Denominator: \[ \int_0^\pi [1 + \lambda P_2(\cos\theta)]\sin\theta\,d\theta = \int_0^\pi \sin\theta\,d\theta + \lambda\int_0^\pi P_2(\cos\theta)\sin\theta\,d\theta \] \[ = 2 + \lambda \cdot 0 = 2 \]

Therefore, the linearized relation is: \[ S = \frac{2\lambda/5}{2} = \frac{\lambda}{5} \]

Find the critical temperature

Substituting \(\lambda = uS/(k_BT)\): \[ S = \frac{uS}{5k_BT} \]

For a non-trivial solution (\(S \neq 0\)), we can divide both sides by \(S\): \[ 1 = \frac{u}{5k_BT} \]

Therefore: \[ \frac{k_BT}{u} = \frac{1}{5} \]

The critical value is \(k_BT_c/u = 1/5\), which is the point at which the instability to the order parameter fluctuations sets in and corresponds therefore to the spinodal point of the isotropic phase.

Let’s think for a moment however about what we have done: we have assumed to stay in the isotropic phase and looked at small perturbations around it that satisfy the self-consistent equation. We have found that trivially the isotropic phase is always a solution. However we have also found that at \(k_BT/u=1/5\) we can change any value of S (provided that it is small enough for the linearisation to hold) into a solution of the self-consistent equation.

This means that at such temperature the isotropic phase becomes marginally stable: any small perturbation in S will not be restored back to zero. This is the definition of a spinodal point.
